Ecrin Guided Session #1
• Ecr
GS01 - 15/37
rin v4.12 - Doc
You can click on the gauge icon to visualize the data:
Filtered Pressure data creation
Right click on the node gauge and select ‘Add
new filtered data’.
Let’s follow the same process as for the production data filtering.
When the filtering dialog appears continue to click
and accept the defaults until the
'Filters' tab is displayed. Leave the filter settings as their defaults suggested by Diamant.
Accept the post-filtration with defaults, click the 'TEST' button, and then proceed
to
.
