Ecrin Guided Session #1
• Ecr
GS01 - 12/37
Choose to 'Resume load' to complete the
loading for the entire data set.
At the end of the process, the 'Load statistics'
dialog displays the global statistics
information. Over the original 2,997,346 raw
measurements, around 30,000
lines have
been actually sampled after filtration. That is
1% of the original dataset size, so one
hundred times smaller than the initial size.
Exit the 'Load data' dialog with an OK.
Fig. C01.16 • Load data finished
Select the 'View Info'
mode for the OIL Rate node: information related to the original file
and loading process has been updated. Switching to the 'View Plot'
mode will display the
OIL rate production plot as seen in Figure C01.18. It can be noticed that although the OIL Rate
has been input as Points, the data can be displayed as points or as steps.
Fig. C01.17 • Oil rate – View Info
Fig. C01.18 • Oil rate – View Plot
Drag and drop the filtered rate data into the Raw Production Oil Rate node.
